A first real alternative to welding.
siFramo is a non-welded steelwork support system for the modular construction of frames and structures.
Engineeric Solutions strive to be innovative and that's why we're proud to announce that we're an approved reseller and installer of Sikla siFramo's Fastening Solutions.
The Sikla Systems within the process industry have been proven for over 20 years and is well-known within investor / end-user projects. Their products have been developed over time in conjunction with applications for the oil, gas, pharmaceutical, chemical, and petrochemical industries.
-
The system enables multidirectional connection possibilities without the need for through-bolts and back-plates.
- On-site building tolerances can easily be overcome by customizing the Sikla products to suit site conditions.
-
The connection method is simple, fast, reliable and safe. The entire system is certified according to international standards.
-
Installation changes can be made easily and without waste or hot works on site.
-
The box section profiles have a high torsional resistance and a fine adjustment capability for connecting members.
How siFramo is assembled:
-
siFramo is assembled via thread forming screws.
-
The non-cutting cold formed threads of the screw form their own threads into the pilot holes of the perforated siFramo profiles.
-
The low thread forming torque and resulting high clamping force, offers a superior process-reliable shake-proof fastening.
-
The thread forming screws are removable and can be used again.
Additional benefits of using Sikla siFramo:
→ Reduced Overall Project Time
→ Detailed Design can be done later and still be adaptable
→ Cost and time advantages regarding transport (earlier or cheaper)
→ More economical (material, installation time, overall)
→ No skilled staff needed, possible to be built by one person
→ Material on stock
→ Fabrication can take place anywhere
→ Weight saving about 50%, hence less/no crane and less man power (costs)
→ Instant corrosion protection (HDG) [Learn more about the corrosion protection here]
→ Static proof by RStab calculations
→ Adjustments and modifications easily possible
→ Reduced impact on the environment
Want to learn more about Sikla siFramo?
Download our Brochure below
